Mili Std - Steel Countersunk Recessed Washer | MS14155-5

• Hole Diameter: 0.314 Inches Minimum And 0.318 Inches Maximum
• Outside Diameter: 0.610 Inches Minimum And 0.620 Inches Maximum
• Material Thickness: 0.114 Inches Minimum And 0.124 Inches Maximum
• Hardness Rating: 39.0 Rockwell C Minimum And 43.0 Rockwell C Maximum
• Top Recess Diameter: 0.399 Inches Minimum And 0.409 Inches Maximum
• Bottom Recess Angle: 90.0 Degrees Nominal
• Top Recess Angle: 90.0 Degrees Nominal
• Bottom Recess Diameter: 0.399 Inches Minimum And 0.409 Inches Maximum
• Material: Steel Comp 4130 Overall
• Material Document And Classification: Mil-S-5059,Ty 302,1/2 Hard Mil Spec 1St Material Response Overall Or Mil-S-18729 Mil Spec 2Nd Material Response Overall
• Surface Treatment: Cadmium Overall and Chromate Overall
• Surface Treatment Document And Classification: QQ-P-416,Ty 2,Cl 2 Fed Spec Single Treatment Response Overall
• Style Designator: Recessed Both Sides
